Post Mounting Options

The post kit includes two 60 x 40 mm aluminium posts, either silver anodised or painted, delivered with four brushed stainless-steel attachment brackets. The installation can be done by concreting directly into the ground or using base plates. Additionally, an extra post can be provided for connecting multiple display cases, delivered with two brushed stainless-steel central attachment brackets to connect multiple display cases. This post option is concreted directly into the ground only. The header panel is made from a 2 mm steel sheet and is available in two shapes: dome or rectangle, both designed to enhance the aesthetic appeal of the notice board.

Optional Add-Ons and Installation

For enhanced visibility, an LED lighting kit is available as an optional add-on. It includes high-efficiency white light with a typical brightness of 120 Lumens per watt, LED IP20, transformers IP67, a lifespan of 75,000 hours, and an energy efficiency of 12.5 watts per linear metre. Please note that LED ribbons and the transformer are not factory-fitted and require installation by a qualified electrician to comply with applicable safety regulations. Installation hardware such as bolts or screws are not included, but the notice board comes with pre-drilled mounting holes, making it easy to attach to a wall or posts using the supplied bolts.

Display: Single Sided

Glazing: 4mm anti-vandal Plexichoc™

Opening System: Side Opening (Reversible)

Locking System: Tamperproof safety lock. Supplied with 2 keys. (2 locks on 12 A4 and 16 A4)

Waterproofing:  Elastomer Seal

Interior Finish:  Galvanised steel sheet lacquered in white on the interior back panel, light grey (RAL 7032) on the exterior back panel.

Frame Finish:  Silver Anodised Aluminium or Painted (see available RAL colours)

Post Kit (Included):  Two 60x40mm aluminum posts either silver anodised or painted to match your chosen colour selection, supplied with four brushed stainless steel attachment brackets. Your posts can either be sunken (root mounted) - concrete fixed below ground level, or with base plates (surface mounted) to be bolted into concrete slabs at ground level. (Concrete mix not included). (12 x A4 and 16 x A4 are root mounted only due to their weight and size).

Included:  Magnets Included (1 per A4, *limit of 20 per display case).

Optional Lighting Kit: PLEASE NOTE Lighting Unit will not be supplied attached to the board. To install the kit, the customer is obliged to drill into the notice board to pass the wires, however,  do not do so on top of the notice board. Once the wires are passed, use silicone both inside and out of the hole to make a waterproof seal. Do not put the transformer inside the case, due to heat this may cause condensation. Please contact us for further information if required.

LED LIGHTING KIT LED

Lighting Kits make it easier to read the documents on display.

• High-quality white light: 120 lumens per watt, IP20 LEDs
• Transformers: IP67
• Life span: 75,000 hours of operation
• Power consumption: 12.5 watts per linear metre
• Caution: electrical connections must be made by a professional and comply with all applicable regulations.

Wiring recommendations (maximum distance per linear metre of LED strip):

• 5 m with 2 x 0.75 mm cable
• 10 m with 2 x 1.5 mm cable
• 15 m with 2 x 2.5 mm cable

Note: our kits consist of one or more LED strips, depending on the size of the notice board, and a transformer.

PRODUCT WARRANTY

Our products are essential elements of urban life. Longevity, durability and your legitimate demand for sustainability require a high level of quality. Cutting, bending, notching, welding, glueing, grinding, sanding, anti-corrosion treatment, finish paint, and packaging: the greatest professionalism is used throughout the manufacturing process. Our approach is to offer a warranty on this product according to the following conditions:

• Weld Strength - 5-Year Warranty
• Quality of paint finish & UV resistance - 5-Year Warranty
• Waterproofness of outdoor noticeboards - 5-Year Warranty
• Resistance of recycled plastic - 5-Year Warranty (excluding deformation and discolouration)
• High-density polyethylene - 5-Year Warranty (excluding discolouration)
• Quality of paints/stains on wood components and their resistance to UV - 1-Year Warranty (untreated wood components are not guaranteed)

Outside the areas specified above, the contractual guarantee is limited to one year.

Product Lead Time – Please be advised the lead time detailed above is the current working standard for this product. Your despatch and delivery dates will be detailed in your order confirmation sent via email from our Sales Team once your order has been received. For any product requiring artwork completion, the lead time starts from the next business day after you have approved and signed off your digital artwork proof. If we cannot fulfil your order within the detailed lead time, you will be contacted immediately about your order.
